V Groove 5.0mm Thickness PCB Separator Machine

    Buy cheap V Groove 5.0mm Thickness PCB Separator Machine from wholesalers

    Buy cheap V Groove 5.0mm Thickness PCB Separator Machine from wholesalers
    • Buy cheap V Groove 5.0mm Thickness PCB Separator Machine from wholesalers

    V Groove 5.0mm Thickness PCB Separator Machine

    Ask Lasest Price
    Brand Name : YUSHUNLI
    Model Number : YSV-1A
    Certification : CE ISO
    Price : USD1000~2900
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 80Sets/Month
    Delivery Time : 10-15work days
    • Product Details
    • Company Profile

    V Groove 5.0mm Thickness PCB Separator Machine

    0.6-5.0mm Thickness V Groove PCB Depanel Machine/PCB Board Separating Machine
    Blades Moving PCB Separator
    Features
    1. Microcomputer program control, precise positioning and good stability.
    2. Separate pre-scored PCB assembly without stress on either PCB or component;
    3. One touch programming of cut length with digital display;
    4. Separating speed is adjusted by a rotary knob;
    5. Handle Intermittent scoring or cut-outs;
    6. Board with projected component can be cut precisely;
    7. Large stainless steel platform on both side of cutting lade prevents board wobble
    and table height and angle are adjustable;
    8. Clearance between circular and linear blades are adjustable to fit different groove
    depth and compensates for blade wear out.
    Application:
    Suitablde for cut SMD aluminum PCB, PCB boards and FR4 fiberglass neatly,
    effectively quickly. Easy to operate and causing no damdage to components on
    boards. Imported high- speed steel blade with long service life, mainly applied in
    circuit board industries such as led, SMT, etc.
    Specs:
    Max Cutting Length
    460mm or 600mm
    Dimension
    740*550*460mm or 880*420*320mm(L*W*H)
    Cutting pooint
    0-100-200-300-400mm
    Cutting Speed
    300mm/s ,500mm/s
    Cutter point angle
    26~28°
    Conveyor Belt (Options)
    1.5 m
    Cutting thickness
    0.6-5.0mm
    Minimum component distance from v-groove
    1mm
    Voltage
    220 V or 110V, 50/60HZ, 250W
    Max component height
    30 mm
    Machine weight
    65kg / 85kg
    Machine Warranty period
    1 year

    Range of application:

    1.It is suitable to cut PCB
    2. Printed Circuit Board
    3. LED Aluminum plate/LED strip/LED light bar
    4. Fiberglass panel/sheet

    1.Available V-cut thickness: from 0.2mm to 2.0mm
    2. Available PCB thickness: from 0.2mm to 3.2 mm
    3. Maximum board length: 1300mm


    Specifications:

    1.For V-cut PCB, Aluminum PCB
    2.PCB thickness:0.2-3.2mm
    3.PCB length:0-1300mm
    4.Fast speed and lowest press
    5.Blade moving
