    High Efficiency /High Quality YSV-1A Blades Moving PCB Separator For SMT Production Line

    Ask Lasest Price
    Brand Name : YUSH
    Model Number : YSV-1A
    Certification : CE, RUV Rheinland (China), GMC(GlobalMarket),ISO9001-2000
    Price : USD1000
    Payment Terms : T/T ,Paypal ,West Union ,L/C ,D/P .
    Supply Ability : 100 sets/ month
    Delivery Time : 3 days
    • Product Details
    • Company Profile

    High Efficiency /High Quality YSV-1A Blades Moving PCB Separator For SMT Production Line

    YSV-1A blades Moving PCB Separator
    Features:
    1. Microcomputer program control, precise positioning and good stability.
    2. Separate pre-scored PCB assembly without stress on either PCB or component;
    3. One touch programming of cut length with digital display
    4. Separating speed is adjusted by a rotary knob
    5. Handle Intermittent scoring or cut-outs
    6. Board with projected component can be cut precisely
    7. Large stainless steel platform on both side of cutting lade prevents board wobble
    and table height and angle are adjustable
    8. Clearance between circular and linear blades are adjustable to fit different groove
    depth and compensates for blade wear out.
    Application:
    Suitablde for cut SMD aluminum PCB, PCB boards and FR4 fiberglass neatly,
    effectively quickly. Easy to operate and causing no damdage to components on
    boards. Imported high- speed steel blade with long service life, mainly applied in
    circuit board industries such as led, SMT, etc.
    Description:
    YSV-1A Specifications
    Model
    YSV-1A
    Max Cutting Length
    460mm or 600mm
    Dimension
    740*550*460mm or
    880*420*320mm(L*W*H)
    Cutting pooint
    0-100-200-300-400mm
    Cutting Speed
    300mm/s ,500mm/s
    Cutter point angle
    26~28°
    Conveyor Belt (Options)
    1.5 m
    Cutting thickness
    0.6-5.0mm
    Minimum component distance from v-groove
    1mm
    Voltage
    220 V or 110V, 50/60HZ, 250W
    Max component height
    30 mm
    Machine weight
    65kg / 85kg
    Machine Warranty period
    1 year
    PACKAGE PHOTO:
    Machine CE certificate:
