YSL-P3P6P12 Semi-Automatic PCB SMT Screen Printer
Introduce of SMT Stencil Printer
1. Using linear guide-ways, matching motor drive speed , ensure the
printing stability and precision.
2. Blade pressure and printing speed is adjustable, precision
pressure gauge, speed controller display.
3. Suspension blade system makes printing more evenly.
4. Modular universal bench, thimble random placement , easy
conversion.
5. With alignment device for PCB board and frame.
6. Work with both single-sided and double-sided PCB boards.
7. Steel frame arms can be adjusted for different size ranges from
370 * 470mm to 1500 * 350mm .
8. Auto printing , stable and efficient printing quality.
Specification of SMT Stencil Printer
| Model | YSL-P3 | YSL-P6 | YSL-P12 |
| Accuracy | +/- 0.05mm | +/- 0.05mm | +/- 0.05mm |
| PCB Size | 300 x 350 mm | 600 x 350 mm | 1200 x 350 mm |
| Platform size | 300 x 350 mm | 700 x 400 mm | 1350 x 400 mm |
| Stencil Size(mm) | 370*470,550*650 | 370*470,550*650 | 370*470,550*650,1500*650 |
| PCB Thickness | 0.2 - 6 mm | 0.2 - 6 mm | 0.2 - 6 mm |
| Stencil Positioning | Manual | Manual | Manual |
| Cycle Time | < 10 Sec. | < 10 Sec. | < 12 Sec. |
| Power Consumption | 200 W | 200 W | 200 W |
| Power Supply | 1 -PH, 220VAC 50/60HZ | 1 -PH, 220VAC 50/60HZ | 1 -PH, 220VAC 50/60HZ |
| Air Pressure | 4.5-6 kg/cm | 4.5-6 kg/cm | 4.5-6 kg/cm |
| Squeegee Speed | 0-1500mm/sec | 0-1500mm/sec | 0-1500mm/sec |
| Dimension | 850x750x1650 mm | 1050x750x1650 mm | 1660x750x1650 mm |
| Weight | 280 Kg | 300 Kg | 356 Kg |
| Squeegee Length | 250mm | 250mm | 250mm |
| Platform Height | 950mm | 950mm | 950mm |
Product pictures are as follows
Keywords:
SMT Stencil Printer, SMT Solder Paste
Printer, SMT Printing Machine, SMT PCB
Printer, 600mm Solder Paste Printer, 1200mm Solder Paste
Printer, Solder Paste Printer, Semi-auto Solder Paste
Printer, SMT Automatic Stencil Printer, PCB Printing
Machine
